Microtek 10KVA/192V iMAXX 3-Phase Input Online UPS

Microtek 10KVA/192V iMAXX 3-Phase Input Online UPS – Transformer-Based Power Backup

The Microtek 10KVA/192V iMAXX 3-Phase Input Online UPS is a professional transformer-based uninterruptible power supply designed to protect business-critical IT infrastructure, commercial equipment and compatible electronic systems from power failures and electrical disturbances.

Featuring 10KVA/8000W output capacity, DSP-controlled IGBT inverter technology, an inbuilt output isolation transformer and an intelligent 8A battery charger, the Microtek iMAXX UPS delivers regulated pure sine wave power for demanding environments.

This model features a three-phase input and single-phase output (3:1) configuration. It is particularly relevant to commercial buildings and facilities where three-phase electrical power is available but a protected single-phase output is required for suitable equipment.

Manufactured by Microtek, the iMAXX Series combines external battery flexibility, intelligent monitoring, Hot Standby support and electrical protection features.

Advanced DSP-Controlled IGBT Technology

The Microtek 10KVA iMAXX Online UPS uses Digital Signal Processing technology with an IGBT-based inverter.

The control system manages electrical conversion, power regulation, system monitoring and operating functions.

Unlike conventional standby UPS systems, an Online UPS continuously supplies compatible connected equipment through its inverter during normal operation.

When the mains supply fails, the battery bank continues supporting inverter operation without a normal mains-to-battery transfer delay.

Microtek specifies zero transfer time from normal AC operation to battery mode.

This functionality helps reduce interruptions for compatible computers, networking systems and electronic equipment that require dependable power availability.

Three-Phase Input and Single-Phase Output Configuration

The Microtek 10KVA/192V iMAXX 3-Phase Input Online UPS features a 3:1 electrical configuration.

It receives power from a supported three-phase supply and delivers regulated single-phase AC output.

This configuration is useful in commercial and institutional environments where three-phase distribution is available and dedicated single-phase power backup is required.

The manufacturer specifies nominal three-phase input voltages of 360V, 380V and 400V AC, with a three-phase, neutral and grounding arrangement.

The default output voltage is 230V AC, with selectable 208V and 220V settings.

The UPS is not the same as a three-phase output UPS. Its protected output remains single-phase.

Electrical distribution, load sizing and installation should be planned by a qualified professional.

10KVA/8000W Capacity with 0.8 Power Factor

The Microtek iMAXX 10KVA Online UPS offers a rated capacity of 10000VA/8000W.

Its 0.8 output power factor provides 8000 watts of rated active power under specified operating conditions.

This capacity makes the UPS suitable for properly sized server equipment, workstations, networking systems and compatible commercial electrical loads.

Before installation, the total connected load should be calculated.

The calculation should consider continuous operating power, startup requirements, equipment characteristics and suitable headroom.

An appropriately designed UPS installation helps reduce overload risks and supports reliable power backup operation.

Inbuilt Output Isolation Transformer

One of the most important features of this Microtek iMAXX model is its inbuilt output isolation transformer.

The integrated transformer provides galvanic isolation within the specified UPS output arrangement.

This design can help reduce certain common-mode electrical disturbances and interference that may affect sensitive electronic devices.

The transformer is included within the UPS cabinet, reducing the need for an additional standalone isolation transformer when the built-in configuration meets the application’s requirements.

This feature is especially relevant to properly designed commercial IT and technical equipment installations.

However, electrical isolation does not replace appropriate earthing, circuit protection or equipment-specific electrical safety requirements.

192V DC External Battery System

The Microtek 10KVA/192V iMAXX Online UPS uses an external 192V DC battery bank.

The standard manufacturer-documented configuration requires 16 compatible 12V batteries connected in series.

External batteries provide backup energy when mains power becomes unavailable.

The supplied commercial product description also mentions an 18-battery option. That alternative must be checked against the exact UPS configuration and manufacturer-supported DC voltage settings before installation.

Customers should not assume that changing from 16 to 18 batteries is possible without a corresponding adjustment or approval.

The external battery bank may use compatible sealed maintenance-free, lead-acid or tubular batteries according to Microtek’s guidance.

Actual backup time depends on the battery capacity, connected load, battery condition, operating temperature and system efficiency.

Intelligent 8 Amp Inbuilt Battery Charger

The Microtek iMAXX 10KVA 3:1 Online UPS includes an 8 Amp inbuilt battery charger.

The manufacturer specifies adjustable charging current settings of 2A, 4A and 8A, with 8A as the default.

These settings support suitable charging arrangements for approved external battery banks.

Battery charging current should be selected according to the installed battery capacity and manufacturer’s requirements.

Correct charger settings help maintain battery readiness for unexpected power interruptions.

Because the battery system operates at high DC voltage, installation, servicing and charger configuration should be performed by qualified personnel.

Optional Additional 4 Amp Charger Module

The Microtek iMAXX 10KVA 192V model supports an additional 4 Amp charger module as an optional accessory.

This provides an expansion option for approved battery charging configurations.

The optional module is separate from the standard 8A inbuilt charger and should not be considered part of the base UPS package unless explicitly included in the quotation.

Customers requiring additional charging capacity should confirm the correct accessory part number and compatibility with the UPS and battery bank.

Any charging expansion must follow Microtek’s installation recommendations.

Pure Sine Wave Output for Sensitive Equipment

The Microtek 10KVA/192V iMAXX Online UPS delivers pure sine wave output.

Pure sine wave technology is suitable for many compatible electronic power supplies and professional computing systems.

The manufacturer specifies a default 230V output, adjustable to 208V or 220V.

Its published output harmonic distortion limits are 3% or less for linear loads and 5% or less for non-linear loads.

The synchronized mains frequency range is 45–55Hz, with battery-mode output at 50Hz ±0.1Hz.

These electrical characteristics help support regulated power delivery under approved operating conditions.

Smart LCD Display for UPS Monitoring

The Microtek iMAXX Series features an LCD monitoring interface that displays useful operating information.

The display assists operators in monitoring the UPS, connected load, battery status and system conditions.

It helps technicians and IT administrators identify important operating alerts and respond to power-related issues.

The UPS also supports communication interfaces for compatible system monitoring.

Optional SNMP management can provide additional network-based monitoring capabilities in supported installations.

These features are relevant to organizations managing critical power equipment within commercial infrastructure.

Hot Standby and Cold Start Functionality

The Microtek 10KVA/192V iMAXX 3-Phase Input Online UPS supports Hot Standby and Cold Start functionality.

Hot Standby can be used in manufacturer-approved standby arrangements where an additional compatible UPS supports backup planning.

The exact standby configuration and required electrical connections should be confirmed with Microtek.

Hot Standby must not automatically be treated as parallel load sharing or increased output capacity.

Cold Start allows the UPS to start under supported battery-powered conditions when a valid battery system is connected.

These features provide flexibility when planning professional backup systems.

Maintenance Bypass and Static Bypass

The Microtek iMAXX Series includes built-in maintenance bypass and static bypass functions.

These features support approved operating and maintenance arrangements.

The manufacturer specifies zero transfer time from inverter to bypass under supported conditions.

However, bypass operation can expose connected loads to the quality of the available bypass supply.

All maintenance and bypass procedures should be performed according to Microtek’s instructions by qualified electrical personnel.

Advanced Electrical Protection Features

The Microtek iMAXX 10KVA Online UPS includes an inbuilt overvoltage cut-off device with surge protection.

It also features conformal-coated PCB assemblies and electrical monitoring functions.

These features help improve reliability in demanding operating environments.

The UPS is designed to respond to specified overload conditions and includes protection-related operating features.

Proper circuit protection, safe grounding, suitable cabling and adequate ventilation remain essential for dependable operation.

Generator Compatibility for Commercial Installations

The Microtek iMAXX Series supports compatible generator power.

This is useful for facilities where a generator is part of a larger backup power installation.

Microtek provides a general generator sizing recommendation of approximately 2.5 times the UPS capacity for the standby source.

Actual generator requirements depend on the installation, connected equipment, charging load and generator output characteristics.

Generator capacity and compatibility should be confirmed by an electrical professional.

CVCF Operation for Regulated Output

The Microtek iMAXX Series supports Constant Voltage Constant Frequency (CVCF) operation under supported conditions.

This mode is useful when an application requires regulated output characteristics.

The manufacturer also describes CVCF operation without a battery bank when valid input power is available.

However, operation without external batteries does not provide backup energy during a complete mains outage.

Customers requiring uninterrupted power backup must install a compatible battery bank.

Professional Applications

The Microtek 10KVA/192V iMAXX 3-Phase Input Online UPS is suitable for properly designed commercial electrical installations.

Potential applications include data center support equipment, server rooms, networking systems, compatible computing infrastructure, office electronic systems and selected laboratory or industrial control equipment.

The three-phase input arrangement makes it relevant to facilities already equipped with suitable three-phase electrical distribution.

Compatibility with medical, industrial or specialized machinery must be checked independently against the equipment manufacturer’s requirements.

UPS capacity, electrical phases, backup runtime and isolation requirements should all be evaluated before purchase.

Professional Installation and Cabinet Design

The Microtek iMAXX 10KVA 3:1 Online UPS has a manufacturer-listed cabinet size of 562 × 300 × 830 mm and an approximate net weight of 115kg.

This makes it a floor-standing commercial UPS requiring appropriate installation space and structural support.

The external battery bank, DC protection, input connections and output wiring must be installed according to approved electrical practices.

Professional installation is important for equipment reliability, safe commissioning and warranty compliance.

Buy Microtek 10KVA/192V iMAXX 3-Phase Input Online UPS from Aadinath Peripherals

At Aadinath Peripherals & Consumables, we supply professional IT hardware, UPS power backup systems, networking equipment, computers and infrastructure products.

We assist businesses, corporate offices, institutions and system integrators with UPS product selection, technical enquiries and bulk procurement.

Customers can review the official Microtek iMAXX technical brochure for manufacturer specifications.

Whether you require a UPS for a commercial office, data center support system or institutional IT installation, selecting the correct phase configuration and battery system is essential.

For pricing, battery configurations, stock availability and bulk quotations, visit Aadinath Peripherals & Consumables or email sales@aadinathperipherals.com.

Technical Specifications
