TVS BS-i201s WL 2D wireless barcode scanner
₹4,699
The TVS-E BS-i201S WL 2D Wireless Barcode Scanner is a versatile handheld barcode reader designed for retail shops, supermarkets, warehouses, pharmacies and POS billing counters. Featuring 150 scans per second, it supports popular 1D and 2D barcodes, including QR Code, Data Matrix, PDF417 and Code 128. Equipped with Bluetooth BLE 4.0 and 2.4GHz wireless connectivity, it offers a transmission range of 30–50 metres in open areas. The scanner includes manual, continuous and automatic scanning modes, offline data storage for up to 512,000 characters, a rechargeable 1400mAh lithium battery and up to 6 hours of battery operation. Its lightweight 130g design makes it practical for everyday wireless barcode scanning.
Product Enquiry
Interested in this product? Fill out the form below.
TVS-E BS-i201S WL 2D Wireless Barcode Scanner
The TVS-E BS-i201S WL 2D Wireless Barcode Scanner is a portable handheld 1D and 2D barcode scanning device designed for retail stores, supermarkets, pharmacies, warehouses, inventory management and Point-of-Sale billing applications.
Featuring Bluetooth BLE 4.0 and 2.4GHz wireless connectivity, a scanning speed of 150 scans per second and support for various barcode formats, the TVS BS-i201S WL provides convenient cordless scanning for everyday commercial operations.
Equipped with a 617nm LED aimer, white LED illumination and multiple scanning modes, the scanner supports efficient barcode capture.
Its built-in storage modes, rechargeable lithium battery and lightweight construction make it suitable for businesses requiring portable scanning capabilities.
Key Features
1. High-Speed 1D and 2D Barcode Scanning
The TVS BS-i201S WL supports a scanning speed of 150 scans per second, helping businesses scan product codes efficiently during billing, stock verification and inventory operations.
The scanner supports common barcode formats including Code 39, Code 93, Code 128, EAN, UPC, QR Code, PDF417, Data Matrix and Aztec.
2. Bluetooth BLE 4.0 and 2.4GHz Wireless Connectivity
The scanner offers two wireless communication methods:
- Bluetooth BLE 4.0: For pairing with compatible Bluetooth-enabled mobile devices.
- 2.4GHz Wireless: For pairing with a dedicated receiver connected to compatible POS or computer systems.
Its stated wireless transmission distance is 30–50 metres in open environments.
3. USB HID Interface
The scanner supports a USB HID interface through its compatible receiver connection, enabling integration with supported computers and billing systems.
4. 617nm LED Aiming Technology
The TVS BS-i201S WL uses a 617nm LED aimer with white LED illumination to assist with barcode positioning and scanning.
5. Multiple Scanning Modes
The scanner supports:
- Manual Scanning
- Continuous Scanning
- Automatic Scanning
These options provide flexibility for different retail and inventory workflows.
6. Offline and Inventory Storage Modes
The TVS BS-i201S WL includes two storage functions.
Offline Storage Mode: When the scanner moves outside the wireless connection range, scanned data can be stored automatically.
Inventory Storage Mode: Allows the scanner to collect barcode information for inventory-related tasks.
The stated storage capacity is 512,000 characters for the supported storage modes.
7. Rechargeable Lithium Battery
The scanner is equipped with a 1400mAh lithium battery, providing:
- Battery Working Time: Up to 6 Hours
- Charging Time: Approximately 3.5 Hours
- Charging Method: USB Charging Cable
Actual battery performance depends on scanning frequency and operating conditions.
8. Barcode Precision and Scanning Range
The scanner offers:
- Scanning Precision: 5 mil or better, as specified
- Minimum Print Contrast: 20% or greater
- Scan Angle: Yaw ±55°, Rotation 360°, Pitch ±55°
- Error Rate: 1 in 5 Million, as stated
Selected barcode scanning ranges include:
- EAN-13: 50–200mm
- QR Code: 25–240mm
- PDF417: 30–130mm
Actual scanning range depends on barcode dimensions and print quality.
9. Durable and Lightweight Construction
The scanner features an ABS+PC housing, measures 90 × 66 × 173mm and weighs approximately 130g.
The supplied specifications state that it can withstand multiple drops from 3 metres onto concrete.
10. Suitable for Commercial Applications
With wireless communication, barcode format support, storage modes and rechargeable operation, the scanner is suitable for everyday retail billing and inventory management applications.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | TVS Electronics (TVS-E) |
| Model | BS-i201S WL |
| Product Type | 2D Wireless Barcode Scanner |
| Scanning Type | Handheld 1D and 2D Barcode Scanner |
| Aiming Light | 617nm LED Aimer |
| Illumination | White LED |
| Scanning Speed | 150 Scans/Second |
| Scanning Modes | Manual, Continuous, Automatic |
| Scanning Precision | ≥5 Mil, as supplied |
| Minimum Print Contrast | ≥20% |
| Yaw Angle | ±55° |
| Rotation | 360° |
| Pitch Angle | ±55° |
| EAN-13 Scanning Range | 50–200mm, under stated conditions |
| QR Code Scanning Range | 25–240mm, under stated conditions |
| PDF417 Scanning Range | 30–130mm, under stated conditions |
| Error Rate | 1 in 5 Million |
| Interface | USB HID |
| Wireless Communication | 2.4GHz and Bluetooth BLE 4.0 |
| Wireless Transmission Distance | 30–50m, Open Area |
| Pairing Mode | One-to-One Receiver Pairing or Bluetooth Mobile Pairing |
| Offline Storage | Up to 512,000 Characters |
| Inventory Storage | Up to 512,000 Characters |
| Battery Type | Rechargeable Lithium |
| Battery Capacity | 1400mAh |
| Battery Working Time | Up to 6 Hours |
| Charging Time | Approximately 3.5 Hours |
| Charging Method | USB Charging Cable |
| Input Voltage | DC 5V ±5% |
| Operating Current (Not Scanning) | ≥26mA, as supplied |
| Standby Current | 0mA in Power-Off Standby, as stated |
| Operating Temperature | -20°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5–95% RH, Non-Condensing |
| Housing Material | ABS + PC |
| Dimensions | 90 × 66 × 173mm |
| Weight | 130g |
| Cable Length | 1.2 Metres |
| Drop Resistance | Multiple 3m Drops onto Concrete, as stated |
| Warranty | Not Specified |
Supported Barcode Formats
1D Barcodes
EAN, UPC, Code 39, Code 93, Code 128, UCC/EAN 128, Codabar, Interleaved 2 of 5, ITF-6, ITF-4, ISBN, ISSN,
