MSI B650 GAMING PLUS WIFI AMD B650 DDR5 AM5 ATX Gaming Motherboard
The MSI B650 GAMING PLUS WIFI is a powerful ATX gaming motherboard featuring the AMD B650 chipset and AM5 socket. Supporting AMD Ryzen 9000, 8000 and 7000 Series processors, it offers DDR5 memory up to 7200+ MT/s (OC), PCIe 4.0, dual M.2 NVMe slots, Wi-Fi 6E, Bluetooth 5.3 and 2.5G LAN. Ideal for gaming, content creation and high-performance desktop builds.
Product Enquiry
Interested in this product? Fill out the form below.
MSI B650 GAMING PLUS WIFI AMD B650 DDR5 Motherboard
The MSI B650 GAMING PLUS WIFI Motherboard is a high-performance ATX motherboard designed for AMD Ryzen desktop processors. Powered by the AMD B650 chipset and AM5 socket, it supports AMD Ryzen 9000, 8000 and 7000 Series CPUs.
Equipped with DDR5 memory, PCIe 4.0 expansion, dual M.2 storage and integrated Wi-Fi 6E, this motherboard offers reliable performance and modern connectivity for gaming and productivity.
Key Features
- AMD B650 Chipset: Designed for AMD Ryzen AM5 desktop processors.
- AM5 Socket: Supports AMD Ryzen 9000, 8000 and 7000 Series CPUs.
- DDR5 Memory: Four DIMM slots supporting up to 256GB RAM.
- Memory Overclocking: DDR5 speeds up to 7200+ MT/s (OC).
- PCIe 4.0 Graphics: High-speed graphics card expansion.
- Dual M.2 Storage: Two PCIe 4.0 x4 NVMe SSD slots.
- Wi-Fi 6E: Advanced wireless networking.
- Bluetooth 5.3: Wireless connectivity for compatible peripherals.
- 2.5G LAN: Fast wired Ethernet networking.
- 12+2+1 Power Design: Enhanced power delivery for Ryzen processors.
- Extended Heatsink: Efficient motherboard thermal management.
- M.2 Shield Frozr: SSD cooling protection.
- Lightning USB 20G: Rear USB Type-C with up to 20Gbps transfer speed.
- AMD EXPO: Supports compatible DDR5 memory overclocking profiles.
- Flash BIOS Button: Convenient BIOS updating.
- ATX Form Factor: Compatible with ATX-supported gaming cabinets.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | MSI |
| Model | B650 GAMING PLUS WIFI |
| Chipset | AMD B650 |
| CPU Socket | AMD AM5 |
| Processor Support | Ryzen 9000 / 8000 / 7000 Series |
| Form Factor | ATX |
| Memory Type | DDR5 |
| Memory Slots | 4 DIMM |
| Maximum RAM | 256GB |
| Memory Speed | Up to 7200+ MT/s (OC) |
| Memory Profile | AMD EXPO |
| Primary PCIe Slot | PCIe 4.0 x16 |
| Additional Expansion | PCIe 4.0 x4, PCIe 3.0 x1 |
| M.2 Slots | 2 × PCIe 4.0 x4 |
| SATA Ports | 4 × SATA 6Gb/s |
| Wireless | Wi-Fi 6E |
| Bluetooth | 5.3 |
| Ethernet | 2.5Gbps LAN |
| Rear USB-C | USB 20Gbps |
| Front USB-C | USB 10Gbps |
| Display Outputs | HDMI 2.1, DisplayPort 1.4 |
| Audio | 7.1-Channel HD Audio |
| Operating System | Windows 10 / 11 64-bit |
| Dimensions | 304.8 × 243.84 mm |
Why Choose MSI B650 GAMING PLUS WIFI?
The MSI B650 GAMING PLUS WIFI combines high-speed DDR5 memory, PCIe 4.0 expansion, fast wireless networking and advanced cooling in a full-size ATX design.
Its dual M.2 slots, 2.5G LAN and powerful memory support make it suitable for gaming PCs, content creation systems and professional desktop builds.
Upgrade your AMD Ryzen desktop with the MSI B650 GAMING PLUS WIFI Motherboard for dependable performance, modern connectivity and flexible expansion.
