Microtek 1KVA/36V MAX+ Online UPS – Reliable Power Backup for IT Applications

The Microtek 1KVA/36V MAX+ Online UPS is a high-performance power backup solution designed to deliver stable and continuous power to sensitive electronic equipment. Featuring advanced high-frequency double-conversion IGBT technology, a 0.9 output power factor and a 36V external battery system, this online UPS provides dependable protection against power interruptions and voltage fluctuations.

With a rated output of 1000VA/900W and a powerful 9.5A inbuilt charger, the Microtek MAX+ Series is a practical choice for businesses, offices, IT professionals and organizations that need reliable power protection for critical computing operations.

Developed by Microtek, this online UPS combines intelligent power management, pure sine wave output, advanced battery charging technology and monitoring features to support consistent performance in professional environments.

High-Frequency Double Conversion Online Technology

The Microtek 1KVA/36V MAX+ Online UPS features high-frequency double-conversion technology designed to improve the quality and stability of power delivered to connected equipment.

Unlike traditional line interactive UPS systems, an online double-conversion UPS continuously supplies power through its inverter during normal operation.

Incoming AC electricity is converted into DC and then converted back into regulated AC power. This arrangement helps isolate the output from various disturbances in the incoming electrical supply.

The UPS also provides zero transfer time when changing from normal online operation to battery mode, helping keep compatible equipment operating during a mains power failure.

This makes the UPS suitable for environments where unexpected power interruptions can disrupt work or affect important electronic systems.

1KVA/900W Capacity with 0.9 Power Factor

The Microtek MAX+ 1KVA UPS delivers 900 watts of rated output power with an output power factor of 0.9.

This allows it to support appropriately sized electrical loads, including compatible computers, professional workstations, network switches and related IT equipment.

The higher wattage rating compared with a conventional 1KVA/800W UPS offers additional flexibility when planning suitable power backup installations.

However, users should always calculate the total power consumption of connected equipment before selecting a UPS.

Operating within the rated capacity and allowing appropriate load headroom helps improve reliability and reduces the possibility of overload conditions.

Pure Sine Wave Output for Sensitive Electronics

The Microtek 1KVA/36V MAX+ Online UPS delivers pure sine wave output during battery operation.

A pure sine wave closely resembles the waveform supplied by the electrical mains, making it suitable for a wide range of compatible electronic power supplies.

The UPS supports selectable output voltages of 200V, 208V, 220V, 230V and 240V AC, allowing users to configure the output according to supported installation requirements.

Precise output voltage regulation helps deliver consistent power to connected equipment.

This feature is especially valuable in computer networks, office infrastructure and other environments where dependable electrical performance is important.

36V External Battery System with Three Batteries

One of the primary features of the Microtek 1KVA/36V MAX+ Online UPS is its external battery configuration.

This model requires a 36V DC battery system consisting of three compatible 12V batteries connected in series.

The external battery arrangement gives users the flexibility to select an appropriate battery capacity according to their required backup duration.

The MAX+ Series supports compatible battery configurations recommended by the manufacturer, including suitable sealed lead-acid battery systems.

Actual backup time depends on the capacity and condition of the installed batteries, connected equipment load, UPS efficiency and environmental conditions.

Customers should verify the battery specifications, wiring, installation accessories and charging compatibility before commissioning the system.

9.5A Inbuilt Charger for Effective Battery Management

The Microtek MAX+ UPS includes a 9.5 Amp inbuilt charger designed to support the charging requirements of its external battery configuration.

The manufacturer also specifies selectable charging current settings of 2A, 4A, 6A and 8A through the LCD interface.

This allows suitable charging current selection according to the battery configuration and manufacturer recommendations.

The charging system works together with advanced battery management technology to support reliable operation and appropriate charging performance.

Correct charger settings are important for maintaining battery health and ensuring dependable backup availability.

Battery selection and charger configuration should be carried out according to approved electrical and installation practices.

Smart LCD Display for Real-Time Monitoring

The Microtek 1KVA/36V MAX+ Online UPS is equipped with a smart LCD display for convenient power system monitoring.

The display provides useful information about UPS operating conditions, allowing users to review important parameters such as input voltage, output voltage, load and battery status.

It also supports identifying certain operating faults and system conditions.

The MAX+ Series offers smart communication functionality and optional SNMP support for compatible monitoring installations.

SNMP can be useful in professional networking environments where equipment status needs to be monitored remotely.

These monitoring capabilities support easier UPS management for businesses and IT administrators.

Advanced Electrical Protection Features

The Microtek MAX+ Series includes multiple protection features designed to improve reliability and safeguard connected equipment.

These include overload protection, an inbuilt overvoltage cut-off device, surge protection, EMI/RFI noise filtering and overheating protection.

Static bypass functionality provides an additional operating path under supported conditions, while advanced input power factor correction helps improve electrical performance.

The UPS is also generator compatible, provided the generator output satisfies the required electrical specifications.

Together, these technologies make the MAX+ Series suitable for professional environments requiring dependable backup and regulated power.

Suitable for Offices, Computer Networks and Business Applications

The Microtek 1KVA/36V MAX+ Online UPS is suitable for multiple professional IT applications when correctly sized and installed.

Typical uses include desktop computers, computer workstations, network routers, switches, small servers, billing systems, office IT equipment and other compatible electronics.

It can also be considered for educational institutions, computer laboratories, small business infrastructure and networking environments.

Organizations planning larger installations can explore our complete office and IT infrastructure setup solutions, including computer hardware, networking equipment, power backup systems and project procurement.

Buy Microtek 1KVA/36V MAX+ Online UPS from Aadinath Peripherals

At Aadinath Peripherals & Consumables, we offer a wide selection of IT hardware, power backup equipment, computers and accessories for business and institutional customers.

Our product offerings support office installations, computer networking projects, corporate procurement and individual business requirements.

Customers can enquire about Microtek Online UPS models, battery requirements, pricing, availability and bulk order quotations.

Whether you need a single online UPS for a workstation or multiple units for an office setup, our team can assist with product selection and procurement requirements.

For further information about the Microtek 1KVA/36V MAX+ Online UPS (899-601-1001), contact Aadinath Peripherals today.

Choose the Microtek MAX+ Series for reliable online power protection, 900W output capacity, pure sine wave technology, 36V battery support and intelligent charging performance.
