Brand |
ZOTAC GAMING
|
|
Model |
GeForce RTXâ„¢ 5060 Twin Edge 8GB
|
|
GPU
|
NVIDIA® GeForce RTX™ 5060
|
| Architecture |
NVIDIA Blackwell
|
|
CUDA Cores |
3,840
|
|
Memory |
8GB GDDR7 |
|
Memory Interface |
128-bit
|
|
Memory Speed |
28 Gbps |
|
Boost Clock |
Up to 2497 MHz
|
|
Bus Interface |
PCI Express 5.0 x8
|
|
Ray Tracing Cores
|
4th Generation RT Cores
|
|
Tensor Cores |
5th Generation Tensor Cores
|
|
AI Features |
NVIDIA DLSS 4, NVIDIA Reflex, NVIDIA Broadcast
|
|
Cooling System |
Dual 90mm BladeLink Fans
|
|
Backplate |
Metal Backplate
|
|
Display Outputs |
3 × DisplayPort 2.1b, 1 × HDMI 2.1b
|
|
Maximum Resolution |
7680 × 4320 (8K)
|
|
Maximum Displays |
4
|
|
DirectX Support |
DirectX 12 Ultimate
|
|
OpenGL Support |
OpenGL 4.6
|
|
Power Consumption |
145 W
|
|
Recommended Power Supply |
550 W
|
|
Power Connector |
1 × 8-pin PCIe
|
|
Card Dimensions |
220.5 × 120.25 × 41.6 mm
|
|
Slot Size |
2-Slot
|
|
Operating System Support |
Windows 10 (64-bit), Windows 11 (64-bit)
|
