Gigabyte AORUS ELITE P850W 850W 80 Plus Platinum Fully Modular PCIe 5.0 Power Supply GP-AE850PM-PG5
The Gigabyte AORUS ELITE P850W Power Supply (GP-AE850PM-PG5) delivers reliable 850W power for gaming PCs and high-performance desktops. Featuring 80 PLUS Platinum certification, ATX 3.0 compliance, PCIe 5.0 support, fully modular cables, 100% Japanese capacitors and a 120mm Fluid Dynamic Bearing fan, this premium SMPS provides efficient cooling, stable power delivery and up to 10 years of manufacturer warranty.
Product Enquiry
Interested in this product? Fill out the form below.
Gigabyte AORUS ELITE P850W 850W 80 PLUS Platinum Fully Modular Power Supply GP-AE850PM-PG5
Upgrade your gaming PC with the Gigabyte AORUS ELITE P850W Power Supply, designed to deliver high efficiency, stable power output and modern graphics card compatibility. Featuring 80 PLUS Platinum certification, ATX 3.0 technology and a fully modular cable system, this premium PSU is suitable for gaming enthusiasts, content creators and performance-focused PC builders.
80 PLUS Platinum Certified Efficiency
The Gigabyte AORUS ELITE P850W achieves 92% power efficiency at 50% load under specified certification test conditions. Its Platinum-rated design helps reduce electrical energy waste, excess heat generation and cooling requirements.
ATX 3.0 and PCIe 5.0 Compatibility
Designed for modern computer hardware, this power supply complies with the Intel ATX 3.0 specification and supports PCIe Gen 5.0 graphics cards. A native 16-pin PCIe power cable can deliver up to 600W to compatible graphics cards, subject to the overall system power budget.
100% Japanese Capacitors
Premium Japanese capacitors provide reliable electrical performance, stable voltage regulation and enhanced durability during demanding computing workloads.
120mm Smart Fluid Dynamic Bearing Fan
The 120mm Fluid Dynamic Bearing (FDB) fan delivers effective cooling with reduced operating noise. Its intelligent fan controller adjusts fan speed according to power requirements and stops the fan when the power supply is idle or operating below approximately 50% load.
Fully Modular Cable Design
The fully modular cable system lets users connect only the necessary power cables. Flat black cables help reduce clutter, enhance internal airflow and simplify installation.
Compact 140mm PSU Length
Featuring a compact 140mm chassis length, the AORUS ELITE P850W offers convenient compatibility with many ATX cabinets while delivering powerful 850W performance.
Customizable AORUS Magnetic Plate
The removable AORUS magnetic plate can be positioned on different sides of the PSU, allowing users to customize the appearance of their gaming PC.
Advanced Electrical Protection
Integrated electrical protection features include Over Voltage Protection (OVP), Over Power Protection (OPP), Short Circuit Protection (SCP), Under Voltage Protection (UVP), Over Current Protection (OCP) and Over Temperature Protection (OTP).
Key Features:
- 850W rated continuous power output
- 80 PLUS Platinum efficiency certification
- 92% efficiency at typical load
- Fully modular cable design
- Intel ATX 3.0 compliance
- Compatible with ATX 3.1 systems
- PCIe Gen 5.0 graphics card support
- Native 16-pin PCIe GPU power connector rated up to 600W
- 100% premium Japanese capacitors
- 120mm smart Fluid Dynamic Bearing cooling fan
- Automatic fan-stop operation below approximately 50% load
- Powerful single +12V rail
- Flat black modular cables
- Two CPU 4+4-pin power connectors
- Six PCIe 6+2-pin connectors
- Eight SATA power connectors
- Four peripheral power connectors
- Compact 140mm PSU length
- Customizable AORUS magnetic plate
- Six electrical protection features
- MTBF greater than 100,000 hours
- 10-year manufacturer warranty, subject to regional terms
Why Choose Gigabyte AORUS ELITE P850W?
The Gigabyte AORUS ELITE P850W Power Supply combines Platinum-rated efficiency, modern PCIe graphics connectivity, premium Japanese capacitors and quiet cooling. Its fully modular design, reliable 850W power output and compact dimensions make it an excellent solution for gaming PCs, professional workstations and custom desktop builds.
 Product Specifications
| Specification | Details |
|---|---|
| Brand | Gigabyte |
| Series | AORUS ELITE |
| Model | P850W |
| Part Number | GP-AE850PM-PG5 |
| Product Type | SMPS / Power Supply |
| Rated Power | 850W |
| Efficiency Certification | 80 PLUS Platinum |
| Typical Load Efficiency | 92% |
| Modular Type | Fully Modular |
| ATX Standard | ATX 3.0 (Rev. 1.0) |
| PCIe Standard | PCIe Gen 5.0 |
| PFC Type | Active PFC (>0.9 typical) |
| Input Voltage | 100–240V AC |
| Input Current | 12–6A |
| Input Frequency | 50–60Hz |
| Cooling Fan | 120mm |
| Fan Bearing | Fluid Dynamic Bearing |
| Capacitors | 100% Japanese Capacitors |
| Motherboard Connector | 1 × 20+4 Pin |
| CPU Connectors | 2 × 4+4 Pin |
| PCIe 16-Pin Connector | 1 |
| PCIe 16-Pin Power | Up to 600W |
| PCIe 6+2-Pin Connectors | 6 |
| SATA Connectors | 8 |
| Peripheral Connectors | 4 |
| Power Rail | Single +12V |
| Cable Type | Flat, Fully Modular |
| Cable Colour | Black |
| Protection Features | OVP, OPP, SCP, UVP, OCP, OTP |
| MTBF | Greater Than 100,000 Hours |
| Hold-Up Time | Greater Than 16ms |
| Power Good Signal | 100–150ms |
| Dimensions | 150 × 140 × 86mm |
| Colour | Black |
| Warranty | Up to 10 Years, Region Dependent |
