ASUS Prime H810M-E DDR5 LGA1851 Motherboard
₹9,920
ASUS Prime H810M-E is a micro-ATX DDR5 motherboard for Intel Core Ultra Series 2 processors. It features an LGA1851 socket, PCIe 4.0 x16, two M.2 slots, four SATA ports, dual DisplayPort, HDMI and Realtek Gigabit Ethernet.
Product Enquiry
Interested in this product? Fill out the form below.
ASUS Prime H810M-E DDR5 LGA1851 Motherboard
The ASUS Prime H810M-E DDR5 Motherboard provides reliable performance and essential connectivity for office computers, home desktops and budget-friendly custom PC builds.
Its Intel H810 chipset and LGA1851 socket support Intel Core Ultra Series 2 desktop processors. The 6+1+1+1 digital power design provides stable power delivery for everyday productivity, multimedia and business applications.
Two DDR5 DIMM slots support up to 128GB of dual-channel memory. Memory speeds of up to 6400 MT/s are supported with Intel Core Ultra 200S processors, while compatible Core Ultra 200S Plus processors support speeds up to 7200 MT/s.
The motherboard includes a PCIe 4.0 x16 slot for a graphics card and two M.2 slots for high-speed NVMe SSDs. Dual DisplayPort and HDMI outputs support multi-monitor configurations when used with a processor featuring integrated graphics.
Key Features
- Intel H810 chipset
- LGA1851 processor socket
- Intel Core Ultra Series 2 processor support
- 6+1+1+1 digital power design
- Two DDR5 DIMM slots
- Maximum memory capacity up to 128GB
- DDR5 speeds up to 7200 MT/s
- PCIe 4.0 x16 SafeSlot Core+
- Two PCIe 4.0 M.2 slots
- Four SATA 6Gbps ports
- Dual DisplayPort outputs
- HDMI 2.1 output
- Realtek Gigabit Ethernet
- Front USB-C 5Gbps connector
- Realtek 7.1-channel HD audio
- ASUS Aura Sync support
- Micro-ATX form factor
Technical Specifications
| Specification | Details |
|---|---|
| Brand | ASUS |
| Series | Prime |
| Model | Prime H810M-E |
| Form Factor | Micro-ATX |
| Chipset | Intel H810 |
| CPU Socket | LGA1851 |
| Processor Support | Intel Core Ultra Series 2 |
| Memory Type | DDR5 |
| Memory Slots | 2 × DIMM |
| Maximum Memory | 128GB |
| Memory Speed | Up to 7200 MT/s |
| Memory Architecture | Dual-channel |
| Main Expansion Slot | 1 × PCIe 4.0 x16 |
| Additional Slot | 1 × PCIe 4.0 x1 |
| M.2 Slots | 2 |
| M.2 Slot 1 | PCIe 4.0 x4 |
| M.2 Slot 2 | PCIe 4.0 x2 |
| SATA Ports | 4 × SATA 6Gbps |
| Wired Network | Realtek 1Gb Ethernet |
| Built-in Wi-Fi | No |
| Built-in Bluetooth | No |
| Rear USB Ports | 6 |
| Front USB-C Header | USB 5Gbps |
| Display Outputs | 2 × DisplayPort 1.4 and HDMI 2.1 |
| Audio | Realtek 7.1 Surround Sound HD Audio |
| RGB Support | Addressable RGB Gen 2 |
| Operating System | Windows 10 and Windows 11 |
| Dimensions | 24.4 × 22.2cm |
